Famousound Max7800 2CHNL 1250W 8OHM Power Amplifier
Title
Regular price
RM 3,700.00
Professional power amplifier with high quality and performance. The highest occupation ratio Class H SMPS product is ideal for various audio systems applications with high performance-cost ratio. Excellent electronic sound performance and power level made superior efficiency in industrial audio systems that requiring low leaking currents, noiseless, and reliable sound performance.
Features
- Adopt stable mature H output circuitry, high efficiency and high cost-performance ratio.
- Power range is from 300-1250W with totally 7 models to apply the need for all kinds of power.
- Brand-new optimal-designed temperature control power gain can effectively improve applicable stability.
- Adopt excellent and reliable components.
- Comprehensive electronic circuit protection like high-frequency squeal, high temperature, over heat, over load, DC output, etc.
- Non-leaky magnetic-ringed transformer is stable and reliable.
- Full automatic installation technology for AI components can assure the consistency of product.
- Removable dust-proof cover is convenient for daily cleanness and maintenance.
- Suitable for application project for senior Karaoke business club, multi-media conference etc.
Specification
- Output Power (RMS) :
- 8 Ω stereo* - 1250W
- 4 Ω stereo* - 1950W
- 2 Ω stereo** - 3000W
- Bridged Mode (RMS) :
- 8 Ω stereo* - 3900W
- 4 Ω stereo** - 6000W
- Frequency Response : 20Hz - 20kHz
- THD+N : <0.05%
- Damping Factor : >200
- Signal to Noise Ratio : >80 dB
- Slew Rate : 20V/μs
- Crosstalk : >60 dB
- Input Sensitivity : 0.775V / 1V / 1.4V
- Input Impedance : Balance 10K Ω / Unbalance 20K Ω
- Voltage Gain (8 Ω) : 42.3 dB
- Output Circuitry : 3-tier Class H
- Indicator Controls :
- Power, Signal, Clop, Protection
- Rear panel
- Bridge
- Front Panel Controls :
- Power switch
- Volume control knob
- Rear Panel Controls :
- Stereo/parallel bridge switch
- Grounding switch
- Connectors (Inputs) :
- XLR Female & XLR Male
- Connectors (Outputs) :
- Binding posts, NL4 Speakon
- Cooling : Air flow from front to rear panel
- Protection :
- Soft start
- DC
- Short circuit
- Over load
- Clip limit
- Over heat
- Progressive volume
- VHF
- Power Requirements :
- AC220V / 50Hz ± 10%
- Non-removable IEC power cord
